Planewave 24 inch Ritchey-Chrétien Optical Tube Assembly

Original price $86,500.00 - Original price $86,500.00
Original price
$86,500.00 - $86,500.00
Current price $86,500.00
SKU 240123Q

Note: To enquire or to place an order please press the Add to Quote button and add as many products to the quote as you are interested in. Add any questions or comments in the Message field. We will then get back to you to discuss your requirements. Alternatively, give us a call.

Click for further details on ordering, payment and shipping.



Delta-T Ready – Now the CDK24 comes standard with built-in dew heaters for both primary and secondary mirror. A $550 value!

Introducing the PlaneWave Instruments PW24-RC, a 24 inch (0.61 m) telescope with Ritchey-Chrétien optics. PlaneWave’s CDK astrographs have become the telescopes of choice for universities, industry, and astrophotographers around the world, and now PlaneWave offers the PW-RC series to meet the custom needs of the scientific community.

The PW24-RC in its native format (no field flattening lenses) uses only a primary and secondary mirror with reflective coatings. This can be useful when making observations primarily on-axis and wide field imaging is not a concern.


Ritchey-Chrétien (RC) Optics

Fused silica RC optics made by PlaneWave for excellent on-axis performance using only a hyperbolic primary and secondary mirror with no refractive optics in the light path.

Carbon Fiber Truss Design

Minimizes thermal expansion to prevent focus shift with changes in temperature

Dovetail expansion joint

Accommodates the difference in thermal expansion between carbon fiber and aluminum. The expansion joint allows the aluminum dovetail to expand and contract without stressing the carbon fiber lower truss

Cooling Fans

Three cooling fans blow out the back of the optical tube, pulling air through the telescope and past the primary mirror. This helps the telescope to reach thermal equilibrium quickly. The fans are controlled by a computer if the optional Electronic Focus Accessory (EFA Kit) is purchased.

Optical System

Optical Design Ritchey-Chrétien (RC)
Aperture 24 inch (610 mm)
Focal Length 6469 mm (254.68 inch)
Focal ratio F/10.6
Central Obstruction 30% of the Primary Mirror Diameter
Back Focus from Mounting Surface 10.3 inch (261.6 mm)
Back Focus from Racked in Focuser 7.3 inch (185.4 mm)
Weight 240 lbs (108.9 kg)
OTA Length 56 inch (1,422 mm)
Upper Cage Carbon Fiber Truss
Lower Cage Carbon Fiber Truss with Aluminum Light Shroud
OTA Width 31 inch (787 mm)
OTA Height 35 inch (889 mm)

Secondary Mirror

Diameter 6.89 inch (175 mm)
Material Fused Silica
Shape Hyperbolic
Coating Enhanced Aluminum – 96%

Primary Mirror

Optical Diameter 24 inch (610 mm)
Outer Diameter 24.5 inch (622 mm)
Shape Hyperbolic
Material Fused Silica
Coating Enhanced Aluminum – 96%


Crated Shipping Weight 500 lbs   (226.8 kg)
Crate Width 40 inch   (1,016 mm)
Crate Height 48 inch   (1,219 mm)
Crate Length 78 inch   (1,981 mm)

Included Accessories

CDK24 Focus Spacer (240343) This 5.3″ long spacer may be installed between the backplate and the focuser to take up some of the CDK24’s extra backfocus and reduce the torque placed on the focuser mechanism. This spacer is sized such that the backfocus distance behind the focuser will match that of the CDK20.
Primary Mirror Cover The Primary Mirror Cover protects the primary mirror.
Planewave thumb drive Includes instructions for Collimation and Spacing and software.
12VDC Power Supply Provides power for the fans (Not included for European Orders)
Wrench Set (5812A35) English Hex Wrenches (European Orders Only)
Recommended Accessories

Mounting Bracket for Finderscopes (125360)

Finderscope and Mounting Bracket (200985)

Visual Adapter – CDK24 (200399)

Delta T Heater Part (240901)

Hendrick Focuser (200340)

IRF90 – Integrated Rotating Focuser (600180)

EFA kit Electronic Focuser (EFA)

Light Shroud CDK24 (240970)

Dovetail Clamp CDK24 (200919)

Piggyback Dovetail Bars (200990)

L-600 Direct Drive Mount (600551)
