Baader M54 Heavy Duty QuickChanging System (consisting of parts #2958760 & #2958765), optical length 15mm

Baader M54 Heavy Duty QuickChanging System (consisting of parts #2958760 & #2958765), optical length 15mm

by Baader Planetarium
SKU M54-QCS (Baader #2958766)
$173.00 - $173.00
$173.00
$173.00 - $173.00
$173.00

Add to Quote

To enquire or to place an order please press the Add to Quote button and add as many products to the quote as you are interested in. Add any questions or comments in the Message field. We will then get back to you to discuss your requirements. Alternatively, give us a call.

Click for further details on ordering, payment and shipping.

Description
  • Heavy Duty M54 Quick Changing System enables lightning-fast changes between cameras, filter wheels or ClickLock eyepiece clamps
  • Optical path length: 15mm
  • Consists of M54i Heavy-Duty Quick Changer with S54i Dovetail receptor (#2958760) and M54a Change Ring with S54a ring dovetail (#2958765)- with 56mm dovetail
  • Quick-changing and rotating device with maximum load capacity
  • 1x M54 Metal Dustcap with S54a ring dovetail (#2958702) included
  • 1x M54 Metal Dustcap with S54a ring dovetail (#2958702) included

Baader Heavy Duty M54 Quick Changing System

A helpful addition to the M54 system is the Heavy Duty M54 Quick Changing System. A combination of quick changer and dovetail will carry any load with maximum safety. It enables the rotation-proof and repeatable holding of heavy accessories.

M54 Quick Changing Ring: The quick changing ring made of high-quality steel has an M48 external thread on one side and a 56mm dovetail on the other. The M54a Change Ring with S54a ring dovetail (#2958765) is also available separately.

M48 Quick Changer: The Quick Changer has a built-in M54 female thread and a high-quality brass pressure piece, so that even very heavy accessories are carried safely and stably. It holds the quick changing ring with dovetail firmly in place. The M54i Heavy-Duty Quick Changer with S54i Dovetail receptor (#2958760) is also available separately.

Specifications
SKU 2958766
EAN Code 4047825060637
Manufacturer Baader Planetarium
Adapters Family M54 System
Optical length (mm) 15
Type of Adapter Same-Thread Adapter
Clamping System Dovetail clamp
Inner Connection (eyepiece/-camera-sided) S54
Inner Connection (lens sided) M54 x 0.75
Screw Type Large clamping screw with brass thrust piece
Inner Diameter / Clear Aperture (mm) 50 mm
Net weight (kg) 0.00
Outer Diameter 65 mm
×





×

×
